• Class II luminaire
• One-piece body in die-cast aluminum casting
• IK08 screen-printed basin
PAINTING :
• RAL powder coating of your choice
• Seaside option
• OPTICAL BLOCK:
– PMMA optical lenses
– Aluminum PCB (3 PCBs maximum)
– Optics: Road (R), Semi-urban (SU), Urban (U), Square (P), Cycle path (PCY), Pedestrian crossing, Architectural.
– Color temperatures: 3000K, 2700K, 2200K, 1800K (4000K, on request) – Coexistence of 2 optional color temperatures*.
– Pre-wired HO7 RN-F flexible (Length depending on equipment)
– ULR < 1%, ULR < 4% (in situ), CIE flux 3 code > 95%
• EQUIPMENT incorporated:
– IP66 waterproofing
– Removable glass opening with 4 captive screws with retaining cable.
– Optional antenna socket (Fixing depending on configuration)
– Driver Light prog, Driver Full prog (With DALI output on request).
SR or D4I driver and socket, optional
*Additional driver for mixed temperature option
• ELECTRICAL PROTECTION:
– 10kV surge protector on request
– Varistor on request
• All our components are ENEC certified
• STANDARD :
– D60 side cap covering (0° inclination – Optional -5°/ -10°)
– Mast top end Ø60mm
• OPTIONAL :
– Ball joint (Free inclination in 5° steps)
– Reduction washer Ø49mm
– Lyre
– Applique
- Eligible for energy-saving certificate
- ENEC-certified components
- RoHS
- DEEE PRO member
- CE 1166
- ISO 9001
- ISO 14001
- Meets the requirements of the Decree of December 27, 2018 on the prevention, reduction and limitation of light pollution.
