– Luminaire with two cast aluminium arms compatible with top 60 mast
– Also available in 3-arm version.
– Luminaire body in die-cast aluminum.
– Serigraphed glass bowl IK08
– Choice of RAL powder-coating, seaside option on request.
Optics and base can be colour-matched.
– OPTICAL COMPARTMENT IP66 :
– Class II luminaire
– Equipped with 1 or 2 PCBs (16 leds or 32 leds, or equivalent)
– PMMA lenses
– Optics: Road (R), Semi-urban (SU), Urban (U), Square (P), Cycle track (PCY), Pedestrian crossing.
– Flux and efficiency table identical to Lolita luminaire, available on request.
– Service life L90B10 100000h
– ULR < 1%, ULR < 4% (in situ), CIE flux code 3 > 95%.
– Color temperature: 3000K as standard. 2700, 2200 and 1800K optional.
– Cohabitation of 2 white tones or one tone and one color to preserve a particular fauna possible on request.
– Standard pre-wiring according to number of PCBs
– REMOTE EQUIPMENT AT MAST FOOT:
– IP66 sealing
– Programmable driver, DALI programmable driver. Optional D4i driver
Volumetrics compatible with existing mast Ø90 mm (please specify when ordering).
– Overvoltage immunity > 6kV (IEC 61010 compliant)
– Specific driver(s) for mixed-source solutions on request.
– OPTIONS :
– zhaga antenna socket on request
– Varistor on request
– All our components are ENEC certified
– STANDARDS :
– End cap for 60mm top mast
Version 2 bras
Version 3 bras
- Eligible for energy-saving certificate
- ENEC-certified components
- RoHS
- WEEE PRO member
- CE 1166
- ISO 9001
- ISO 14001
- Meets the requirements of the Decree of December 27, 2018 on the prevention, reduction and limitation of light pollution.
